SPECIFICATIONS

Color: K C M Y W

Compatible brand of print head: Epson

Ink Capacity: 5*1.5L

Ink Type: Pigment Ink

Material: Stainless Steel

Plate Type: Roll-To-Roll Printer,DTF printer

Precision Mode: VSD 3

Print Width: 600mm/300mm

Printhead: EPN i3200

Printheads Number: 2/4/5

Product name: Fluorescent DTF Printer

RIP Software: Maintop/Optional

Voltage: 220 V

Warranty: 1 year

automatic grade: Full-Automatic

brand name: po-try

color & page: Multicolor

condition: New

dimensions(l*w*h): L1750mm*W790mm*H1500mm

ink type: DTF Ink,Pigment Ink,water based Pigment ink

place of origin: Guangdong, China

warranty: 1 Year

weight: 150

PRODUCT PARAMETERS		PRODUCT PARAMETERS
Model	Printer: HT-0602IA Powder Shaker: PS-0608-MA-V1.0 (220V Manual))
Printhead Type	EPSON I3200-A1
Printhead Quantity	2
Printing Speed	4pass: 12m2/H 6pass: 8m2/H
Printing Width	600mm
Ink Type	Pigment Ink
Ink Capacity	5*1.5L
File Format	TIF / PNG
Color Mode	K C M Y W
Working Condition	Temperature: 20°C-28°C, Humidity: 40%-60%
Take Up System	Constant tension film winding system
Printing Interface	Network interface
RIP Software	Maintop 6.1 / PO-TRY RIP / Photoprint / CADlink
PC Requirements	W7 or above, 64 bit, CPU Processor i5 or above, 8G Storage, C disk with solid state hard drive 120G or above,Attached disk 1TB, Gigabit Ethernet port
Input Voltage	Printer: AC220V/110V±%10, 50/60 Hz      Powder Shaker: AC 220V
Power Consumption	Printer: 550W         Powder shaker: Rated power 1300W, peak power 2200W
Printer Size	Printer: L1750mm*W790mm*H1500mm      Powder Shaker: L1500mm*W840mm*H1020mm
Packing Size	Printer: L1830mm*W810mm*H520mm     Powder Shaker: L1700mm*W960mm*H1150mm
Net Weight	Printer: 150KG           Powder shaker: 194KG
Gross Weight	Printer: 188KG           Powder shaker: 220KG
