SPECIFICATIONS

3000Mbps WiFi6 Wireless Wall-mounted AP Color: White

3000Mbps Wifi Ceiling AP DDR: 128MB

3000Mbps wifi6 AP Antenna: Built in 4*3dBiAntennas

802 11ax comfast access point Power Adapter: 48V 0.5A POE PowerAdapter(Configured)

Brand Name: comfast

Ceiling-mounted AP Output Power (Max): 26dBm

Certification: CE,FCC

Choice: yes

High-concerned chemical: None

Model Number: CF-E393AX

Origin: Mainland China

Package: Yes

Repeater wifi ap: wifi access point

Wall-mounted Ceiling AP Chipset: MT7981A+MT7976D+MT7531AE

WiFi Coverage AP 5GHz: 2400Mbps

Wifi 6 Ceiling AP Flash: 16MB

Wireless Protocol: 802.11n

access point 802.11ax: Wireless router korean

access point wifi: wifi 6 access point

access point wifi ap: acess point wifi 6

access points accessories: comfast wifi repeater

access points wifi 6: acess point wifi

acess point Router: wifi access point

ax3000 access point: access point poe

booster wifi 6: wifi 6 ap

ceiling access point wifi 6: in wall access point

comfast access point: enhanced wifi signal

comfast access point AX3000: ax3000 wifi 6 router

gigabit access point 802.11ax/ac/n/a Frequency: 5.18Ghz-5.825Ghz

gigabit access point poe: access point 5ghz

poe access point: router ax3000 wifi 6 router

route wifi 6 MIMO-OFDM (11ac): MCS 0-9

router wifi 6: wifi 6 access point

semi_Choice: yes

wifi 6 Access Point 2.4GHz: 574Mbps

wifi 6 access point: access point wifi 6

wifi 6 access point 5ghz Installation Way: Ceiling-mounted, Wall-mounted

wifi 6 access point 5ghz Power Supply: 802.3af/802.3at POE Power Supply(0-100m)

wifi 6 access point Receiving Sensitivity (Max): -96dBm

wifi 6 access point ax3000: wifi6 access point poe

wifi 6 access point poe 802.11b/g/n Frequency: 802.11b/g/n: 2.412GHz-2.4835GHz

wifi 6 access points WAN RJ45 Ethernet Port: 1* 10/100/1000Mbps

wifi 6 ax access point MIMO-OFDM (11n): MCS 0-15

wifi 6 ceiling ap LAN RJ45 Ethernet Port: 1* 10/100/1000Mbps

wifi 6 range extenders MIMO-OFDMA (11ac): MCS 0-11

wifi 6 router: wifi range extender

wifi router 6: router wifi

wifi6 booster: wireless access point

wifi6e access point poe: wireless access point wifi 6

WiFi6 High Power Ceiling AP AX3000 Gigabit Wireless Cover Access Point Router 2.4G 5Ghz 802.11AX Wi-Fi POE MU-MIMO CF-E393AX

Description:

This is an enterprise-grade Wifi6 ceiling wireless AP with PoE and high gain antennas, ensure a stable connection in indoor high-density wireless coverage environment.

It operates at 2.4GHz and 5.8GHz dual band, adopts new generation Wi-Fi 6(802.11ax) technologies and comply with IEEE 802.11a/b/g/n/ac/ax standards, the Wi-Fi data rate is up to 3000Mbps.

It supports ULMU-MIMO, OFDMA and 1024QAM technology. It provides a cost-effective solution for indoor wireless network applications like villa, office, hotel, restaurants, shopping mall, stores, schools etc.

Using a powerful intelligent three-chip solution, the performance is guaranteed, and more stable long-term operation.

Main Features:

1、Comply with IEEE 802.11a/b/g/n/ac/ax standards, the Wi-Fi data rate is up to 3000Mbps.

2、High RF power and high gain antennas design significantly enhance the stability of wireless signal and extends wireless range to reduce dead spots.

3、Advanced RF optimization with automatic channel, power level selection to reduce interference. AP can recognize various channels being used and automatically switch to the best available channel to provide best experience for the users.

4、1* 10/100/1000Mbps LAN ports;1* 10/100/1000Mbps WAN ports

5、PoE power supply by combining your power and data connection into a single cable makes outdoor deployment simple and fast.

6、Full gigabit network port transmission, stronger signal, no fear of multi-wall barriers, extended signal without weakening, wider coverage, 360° all-round elimination of WiFi dead spots

7、 Seamless roaming

Package Included:

1x 11ax WiFi6 Ceiling Access Point

1x 48V POE Power adapter

1x Ethernet LAN Cable

1x User ManualPerformance Upgrade High Speed

Wifi 6 full signal coverage , enjoy seamless roaming freedom.One-click deployment , enjoy enterprise-level Wifi treatment .Innovation Wifi6 Smart Choice

Compared with Wifi5 , faster speed and higher capacity ,meet the high-speed Internet needs in multi-user and high-bandwidth scenarios

Higher Speed

Through 10240AM modulation , higher number of subcarriers and 60MHZ bandwidth technology , the unlimited rate is increased to 2976mbps

Larger Capacity

802.11ax adopts OFDMA and DL/ULMU-MIMO technology , which increases the network capacity by 4 times compared with 802 .11ac ;TWT technology , AP can uniformly schedule terminal wake-up and sleep activities to meet the access needs of a large number of terminal devices

Wider Coverage

802.11ax uses a better Long OFDM symbol transmission mechanism and 2MHZ narrowband transmission to effectively reduce the terminal packet loss rate , improve the terminal receiving sensitivity , and have wider Wifi coverage

Anti-interference

802.11ax supports BSS color code , dynamic CCA threshold and power control , which can effectively alleviate the problem of co-channel interference in multi-user scenariosWifi Range Full Signal Coverage

Wifi 6 standard and Strong three chips , built in high power PA ,to meet high density scenes wifi range requirementsGigabit Ethernet Port ,Satisfied Your Higher Demands

Wired transmission rate much fasterDual band Wifi wireless ceiling AP

Dual band 2.4GHZ & 5.8GHZ 3000mbps wireless AP can supports users to automatically choose different frequency and better signal which is more freedom and better experience for users

Reduce latency Enjoy high speed network

Multiple users can connect simultaneously and latency lower to 10ms , and smoother networkDual POE power supply

Don't need to plug power adapter again,one network cable can transmit date and powerAC Management Unified Management of AP

It's matched with COMFAST AC management device which can unified management and automatically configure of large quantity of wireless ceiling AP simultaneouslySeamless roaming FunctionInstallation Diagram

Ceiling-mount Installation

1.Remove the chassis of the ceiling AP and fix it with four screws on the ceiling

2.Fix chassis on the AP

3.finished

Wall-mounted Installation

1.Remove the chassis of the ceiling AP and fix it with four screws on the wall

2.Fix chassis on the AP

3.finishedApplication multi-scenes

Provide Wifi coverage and marketing solution for varieties of scenes

A:This indoor access point , as for no obstacles environment, it can cover 200-500square.

Q2.How Many pieces included in the package ?Does it included poe adapter?

A:The package included the 1pcs access point and 1pcs 48V poe adapter and 1pcs network cable and accessories Screws ,Install guide,  Warranty Card;

Q3. What is the firmware language ?What language can i change to ?

A: The access Point support English and Chinese ,generally you can choose English when setting ;

Q4.How many users can connected at the same time ?

Q5.Does the access point support openwrt ddwrt ?

Q6.How many ssid can be set in this access point ?

Q7.Does the access point support 48V poe switch?

Q8.Does it work as a WiFi repeater?

Q9:Does it support 5G?
