SPECIFICATIONS

Body Material: Brass

Coil Material: Copper

Function: 2/2 Way

Standard or Nonstandard: Standard

Supply Voltage: 12~240V AC/DC

Type: Normal Closed

Voltage: AC 220 V,Dc 12V,AC 110 V,Dc 24V

application: General

brand name: EPSolid

customized support: OEM,ODM,OBM,Software Reengineering

media: Steam

model number: US/2L

place of origin: Zhejiang, China

port size: 1/8''~4''

power: Solenoid

structure: Control

temperature of media: High Temperature

warranty: 1 years

Product Description

Title goes here.

Model 2L170-10 2L170-15 2L170-20 2L200-25 2L300-40 2L500-50
Fluid Air, Water, Steam
Operation Guide type
Type Normal close type
Aperture (mm) 17 22 30 50
Cv value 4.8 12 20 48
Port size 3/8'' 1/2'' 3/4'' 1'' 1 1/2'' 2''
Operation fl uid viscosity 20 CST Below
Operating pressure 0.1 ~ 1.5MPa
Max. Proof pressure 2.25MPa
Operating temperature -5 ~ 180C
Voltage range ±10%
Material of body Brass(Option: Stainless Steel)
Material of oil seal PTFE
