Valvula De Agua De 3 Vias 5v 12v Dn8 DN15 DN20 BSP Laton CR01 CR02 CWX-25S Valvula De Agua Electrica De 3 Vias
Valvula De Agua De 3 Vias 5v 12v Dn8 DN15 DN20 BSP Laton CR01 CR02 CWX-25S Valvula De Agua Electrica De 3 Vias
Couldn't load pickup availability
SPECIFICATIONS
Ball Material: brass
Certificado: ISO,CE
Connection Type: Thread
Escribe: with manual override & position indicator
Modo de control: CR01 CR02 CR03 CR04 CR05
Nombre del producto: Valvula de agua de 3 vias CWX-25S valvula de agua electrica de 3 vias
Port Size: DN8 DN15 DN20
Tipo de hilo: BSP
Tipo de puerto: reduced bore,full port
Voltaje nominal: DC5V, DC3-6V,ADC9-24V, AC85-265V,
application: General
brand name: CWX CWX-25S
color: blue
customized support: OEM
material: brass
media: Water
model number: CWX-25S
place of origin: Tianjin, China
power: Electric
structure: Ball
temperature of media: Normal Temperature
tipo de valvula: electric 3 way water valve
warranty: 12 months
1.POM material gear box ;
2.Manual Override, the valve can be operated when power failure;
3.Min dimension and position indicator
4.good sealing performance, IP65 enclosure
1. Caja de cambios de material POM; valvula de agua electrica de 3 vias
2. Anulación manual, la válvula se puede operar cuando falla la energía;
3. Indicador de posición y dimensión mínima
4. buen rendimiento de sellado, carcasa IP65
1.Heat energy meters, fire work, save water system
2.Auto control system, industrial mini auto control equipment
3.Water saving equipment, drinking water equipment
4.Air-conditioning fan coin(HVAC)
1. Medidores de energía térmica, fuegos artificiales, sistema de ahorro de agua.
2. Sistema de control automático, mini equipo de control automático industrial
3. Equipos de ahorro de agua, equipos de agua potable.
4. Moneda de ventilador de aire acondicionado (HVAC)
| Product model | Rated voltage | Working current | Output torque | Open/close time | Control mode |
| CWX-25S |
DC3-6V DC12V A/DC9-24V AC220V AC85-265V |
Max80mA | Max2.5NM | <8s | CR01 CR02 CR03 CR04 CR05 |
| Working pressure | Power | Medium temperature | Size | IP Gard | Special function |
| Max1.0Mpa | <2W | 0-90℃ | DN8-32 Two-way DN8-20 Three-way | IP65 | Wireless switch control (within 200 meters) |
| Brass | Connection | Sizes | d | L | H |
| Both female thread Full-port | DN8 | 8 | 46 | 31 | |
| DN15 | 15 | 57 | 38 | ||
| DN20 | 20 | 71 | 45 | ||
| DN25 | 23.5 | 72 | 49 | ||
| Both female thread Reduce-port | DN10 | 8 | 46 | 31 | |
| DN20 | 15 | 66 | 38 | ||
| DN25 | 20 | 72 | 47 | ||
| DN32 | 25 | 86 | 60 | ||
|
Vertica Three-Way |
DN15 | 12 | 63 | 49 | |
| DN20 | 15 | 66 | 53 | ||
|
Female-male thread |
DN15 | 15 | 63 | 38 | |
| DN20 | 15 | 66 | 38 | ||
| Both male thread | DN15 | 15 | 68 | 38 | |
| SS304/316 | Both female thread | DN8 | 8 | 46 | 31 |
| DN10 | 8 | 46 | 30.5 | ||
| DN15 | 15 | 55 | 38 | ||
| DN20 | 15 | 63 | 39 | ||
| DN20 | 20 | 71 | 45 | ||
| DN25 | 20 | 75 | 47 | ||
| DN25 | 25 | 72 | 49 |
Tianjin Tianfei High-Tech Valve Co., Ltd. is a professional manufacturer of electric valve and manual valve, is a founding company of Tianjin Valve industry.Tianfei has a professional valvula de agua de 3 vias
R & D team,has won many letters of petent and the recognition of the Tianjin municipal government departments.“CWX”is our brand and our company has passed the
ISO9001,CE,RoHS,NSF61 certificate and so on,the products have exported to many countries and regions worldwide. valvula de agua electrica de 3 vias
Our company motto is novative, simplified, high-valued, As having accumulated rich experiences and resources during more than 10 years developing, we are confident in providing you satisfied products and service in the cooperation. Tianfei pays attention to the quality of the products,use “CWX” valve is your correct choice. valvula de agua electrica de 3 vias
