SPECIFICATIONS

Brand Name: Topton

Graphics Card Type: Integrated Card

Hard Drive Capacity: ≥ 1.5TB

High-concerned chemical: None

Memory Capacity: ≥ 4GB

Model Number: FU02

Origin: Mainland China

Processor Brand: AMD

Processor Model: AMD

Type: Mini Desktop,Mini PC

Use: Multimedia

Processor parameter for referance only

Processors	Cores & Threads	Cache	Base Frequency	Max Turbo Frequency	TDP	Graphics
Ryen 7 7730U	8 cores, 16 threads	16M	2.00 GHz	4.50 GHz	15W	AMD Radeon Graphics 8 Core
Ryzen 7 5825U	8 cores, 16 threads	16M	2.00 GHz	4.50 GHz	15W	AMD Radeon Graphics 8 Core
Ryzen 5 5625U	6 cores, 12 threads	16M	2.30 GHz	4.30 GHz	15W	AMD Radeon Graphics 7 Core
Ryzen 9 4950U	8 cores, 16 threads	8M	1.80 GHz	4.30 GHz	15W	AMD Radeon Graphics 8 Core
Ryzen 7 4700U	8 cores, 8 threads	8M	2.00 GHz	4.10 GHz	15W	AMD Radeon Graphics 7 Core
Ryzen 5 4500U	6 cores, 6 threads	8M	2.30 GHz	4.00 GHz	15W	AMD Radeon Graphics 6 Core

Model: FU02
Dimension:180mm(L)x126.5mm(W)x62.5mm(H)
CPU: AMD Ryzen series
GPU: AMD Radeon Graphics
Ram: 2 x So-DIMM DDR4 slots, support max 64GB 2666/3200MHz
SSD: Support M.2 2280 NVME/PCIE3.0x4
HDD: Support 2.5inch 7mm HDD/SSD
WiFi: AX WiFi6 with Bluethooth5.2(except barebone bundle)
RJ45: 2 x 100/1000M
Front I/O: 1 x USB 3.1, 1 x Mic in/out, 1 x Switch
Rear I/O: 2 x USB 3.1, 2 x USB 2.0, 2 x HDMI2.0, 2 x RJ45 LAN, 1 x DC IN
Feature: Fanless design, aluminum shell as heat-sink, totally silent

Function: Auto power on(open model, unable to close)

What's in the package

1xMini PC

1xPower supply

1xPower cable( we ship EU/US/UK/AU power plug base on buyer's address )

1xSATA cable

2xAntennas

Notice

Barebone Mini PC ("No Ram No HD No WiFi" bundle) package DO NOT include WiFi6 module. Other bundles include WiFi6 module.
