SPECIFICATIONS

Brand Name: Topton

Certification: CE,FCC,RoHS

Graphics Card Type: Integrated Card

Hard Drive Capacity: 512GB

High-concerned chemical: None

Memory Capacity: ≥ 4GB

Model Number: X6E

Origin: Mainland China

Processor Brand: Intel

Processor Model: Pentium 8505 7505/Celeron 6305

Type: Mini Desktop,Mini PC

Use: Commercial

Processorparameter for referance only

Processors	Cores & Threads	L3 Cache	Max Turbo Frequency	TDP
Pentium Gold 8505	5 cores, 6 threads	8M	4.40 GHz	15W
Pentium Gold 7505	2 cores, 4 threads	4M	3.50 GHz	15W
Celeron 6305	2 cores, 2 threads	4M	1.80 GHz	15W

Product Highlight

Pentium 8505 Model:

-6xIntel i226-V 2.5G RJ45 LANs, 3xUSB3.2, 1xUSB2.0, 1xType-C USB2.0, 1xRJ45 COM console.

-2xDDR5 SODIMM non-ECC ram slots, support max 64GB 4800MHz.

-Support 4 storages: 2xM.2 2280 NVMe/PCIex4 SSD(one on each side of motherboard)+2xSATA3.0 SSD/HDD.

Intel N100 Model:

-6xIntel i226-V 2.5G RJ45 LANs, 2xUSB3.2, 2xUSB2.0, 1xType-C USB2.0, 1xRJ45 COM console.

-1xDDR4 SODIMM non-ECC ram slots, support max 32GB 2400/2666/3200MHz.

-Support 2 storages: 1xM.2 2280 NVMe/PCIe3.0x1 SSD+1xSATA3.0 SSD/HDD.

Pentium Gold 7505/Celeron 6305 Model:

-6xIntel i226-V 2.5G RJ45 LANs, 2xUSB3.0, 2xUSB2.0, 1xType-C, 1xRJ45 COM console.

-2xDDR4 SODIMM non-ECC ram slot, support max 64GB 3200MHz.

-Support 3 storages: 1xM.2 2280 NVMe/PCIe3.0x4 SSD+2xSATA3.0 SSD/HDD.

-Support 1xHDMI,1xDP, 1xType-C 4K@60Hz 3 screens display.

-1xM.2 2230 slot supports WiFi module(optional to buy).

-Support AES-NI, ESXI, PVE, Watchdog, Auto power on, RTC, PXE boot, Wake-on-LAN etc.

-Fanless system was equipped with solid aluminum alloy shell as heat-sink, provided same motherboard with 2 different cases for option, Big Case with sharper and larger area fins get a better cooling performance, Small Case was compact with lighter weight to carry. Both work without noise. A internal 8010 fan was included in package for DIY if you still worry about heat.

-Suggest to install pfSense, OPNsense etc routing system. Do not recommend to install Proxmox, ESXi etc virtual machine system without fan.

Package List

1xMini PC

1xPower Adapter

1xPower Cable(EU/US/UK/AU plug based on buyer's country)

1xSATA Cable
1xScrews Bag

1x8010 fan(gift)
